Brand: Big Tex Trailers
BIG TEX 14PI – 7 ft Wide – 14000 LB. GVWR Tandem Axle Wood Floor
The 14PI from Big Tex Trailers is a heavy duty, pipe top equipment trailer. This unit comes standard with an adjustable forged coupler, LED lights, and treated floor.
Model(s): 14PI-16, 14PI-18, 14PI-20
Available Sizes: 7×16′, 7×18′, 7×20′
*** Available in High Mesh Sides ***
Call or Stop by your local Truck’n America today!
 |
 |
FEATURES
(4) Tie Down Pockets on Outside Frame
Adjustable 14K Cast Coupler
Set-Back, 7,000# Drop Leg Jack
Fold Back/Wrap Tongue (14’ & Longer)
EZ Lube Hubs
Dexter Brand Axles
Nev-R-Adjust Electric Brakes on All Hubs
Cambered Axles
Heavy Duty 3” Square Tube Top Rail
Double Broke Diamond Plate Fenders
Grommet Mount Sealed Lighting
L.E.D. Lighting Package
Protected Wiring
Spare Tire Mount (Side)
4’ Slide-In Ramps (Channel)
Complete Break-A-Way System w/Charger
Radial Tires
Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
SPECIFICATIONS
G.V.W.R. 14,000#
G.A.W.R. (Ea. Axle) 7,000#
Coupler Adjustable 2-5/16” 14,000# Cast
Safety Chains 3/8” Grd. 70 w/Safety Latch Hook (2 each)
Jack 7,000# Drop Leg Jack (Bolted On)
Tongue 6” Channel Fold Back/Wrap
Top Rail 3” Square Tube Square Back
Frame 5” x 3” x 5/16” Angle
Crossmembers 3” Channel on 16” Centers
Uprights 15” Tall – 3” x 2” x 3/16” Angle
Fenders 9” x 72” Double Broke Diamond Plate w/Back
Axles (2) 7,000#, EZ Lube w/Electric Brakes
Suspension Multi-Leaf Slipper Spring w/Equalizer
Tire ST235/80 R-16 Load Range E
Wheel 16″ x 6″; Heavy White Mod 8 Bolt
Floor 2″ Treated Pine or Douglas Fir*
Lights LED D.O.T. Stop, Tail, Turn, & Clearance
Elec. Plug 7-Way RV
Finish (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish
Finish Superior Quality Finish is Applied for a Highly Decorative and Protective Finish
*Douglas Fir Available from Caldwell, ID Facility Only
Model# Weight Description
14PI-16 2,740# 83” x 16’ HD Tandem Axle Pipe Top Utility Trailer
14PI-18 2,890# 83” x 18’ HD Tandem Axle Pipe Top Utility Trailer
14PI-20 3,040# 83” x 20’ HD Tandem Axle Pipe Top Utility Trailer
Dimensions
Length A B C
16’ 193-1/2” 115” 78-1/2”
18’ 217-1/2” 127” 90-1/2”
20’ 240” 138” 102”
