American Landmaster – L4 – 4×2 2024 – Side-By-Side 4×2 UTV

Call for price

STARTING AT

$8,999*

DESTINATION CHARGE & SETUP FEES EXTRA. FREIGHT SURCHARGE $250

Brand: American Landmaster

Categories: ,
Call NowCall NowRequest Quote

Description

L4 – 4×2 2024

POWERFUL EFI 4×2, NARROW DESIGN

The new EFI (Electronic Fuel Injected) L4 4×2 is an easy-to-use, easy-to-maintain, highly capable machine for medium-duty tasks. The slim design of the L4 allows for better maneuverability around tight corners and easier access for trails and walkways.

If you plan to use your UTV for plowing, going in deep wet mud, or over extremely uneven terrains, the 4×4 may be a better fit.

PRO TIP: The L4 is able to fit in the back of a pickup truck due to it’s slim design.

Features

OVER 30+ NEW CUSTOMER-INSPIRED FEATURES

SAFETY, SERVICE, RELIABILITY

OVERHEAD BARS ROPS CERTIFIED (Roll-Over Protection System)

1-YEAR FULL BUMPER-TO-BUMPER WARRANTY

BUILT WITH NAME-BRAND AND HIGHLY RELIABLE USA COMPONENTS

EASY ACCESS FOR SERVICEABILITY

WARNING INDICATOR LIGHTS

FULLY SEALED HALF-SHAFT BOOTS & TIE ROD ENDS

HIGH-IMPACT / HIGH-TEMP RESISTANT BUSHINGS

AUTO-GRADE BALL JOINTS

IMPROVED WHEEL HUB AND BEARING

PARKING BRAKE LEVER IMPROVED LOCATION AND INDICATOR LIGHT

WEATHER-SEALED WIRING CONNECTIONS

PERFORMANCE

L-ROSS – LANDMASTER RIDE OPTIMIZED SUSPENSION SYSTEM

4-WHEEL HYDRAULIC DISC BRAKES

IMPROVED RACK AND PINION GEARING

AUTOMOTIVE-QUALITY PLUG & PLAY ELECTRICAL SYSTEM

EFI ENGINE

BEST-IN-CLASS COMFORT, PERFORMANCE, AND CAPABILITY IN YOUR SHOCKS

OVER 8″ OF SUSPENSION TRAVEL FOR BOTH FRONT AND REAR SUSPENSIONS

DESIGN

TWO-TONE DESIGN INTERIOR AND EXTERIOR

NEW SIDE SKIRTS AND FENDERS

NEW AGGRESSIVE FRONT-END LOOK

PROTECTED WINCH LOCATION

NEW FLAT ROOF DESIGN

ALL NEW DECALS AND BADGING

ELECTRIC PACKAGES TO FIT YOUR NEEDS

MARINE-GRADE, HIGH-DENSITY FOAM, CONTOURED SEATS

AUTOMOTIVE-GRADE, WATERPROOF, BACK-LIT SWITCHES

EASY GRIP N’ LOCK DRIVE & DIFFERENTIAL LEVER

RIDE EXPERIENCE
QUIETER DRIVING EXPERIENCE
Thanks to an improved muffler, fenders, side skirts, and catalytic converter.VERSATILITY FOR WORK, TRAILS, COMFORT, SPEEDIMPROVED STEERING SYSTEMINDUSTRY-LEADING TURNING RADIUS OF 12ftAUTOMOTIVE-QUALITY PLUG & PLAY ELECTRICAL SYSTEM

Specifications

POWER
VANGUAR EFI 14hp motor with electronic throttle control

SPEED
Up to 24 mph**
FUEL CONSUMPTION
Up to 20 mpg**
RANGE
Up to 100 miles**
STARTING
12V keyed ignition with recoil backup
BATTERY
12V / 360 cca utility class
SPARK PLUG
NGK BPR6ES
FUEL CAPACITY
5.0 gal
ALTERNATOR
25 amp
TRANSMISSION
CVT automatic
TRANSAXLE
Gear drive Schafer/DANA oil-filled transaxle
DIFFERENTIAL
Cable Actuated Rear-Locking
DRIVE
2 wheel drive
FRONT SUSPENSION
Double A-arms, adjustable coilover shock with up to 7″ travel
REAR SUSPENSION
Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coilover shock with up to 8″ of travel
BRAKE SYSTEM
4 wheel disk, hydraulic brake
TIRES
25 x 8 – 12 (front) 25 x 10 – 12 (rear)
DIMENSIONS
95” L x 53” W x 76” H
WHEEL BASE
73”
TURNING RADIUS
7.5’ inside radius
CURB WEIGHT
1,100 LBS
BED MATERIAL
Structural foam “Poly Bed” with stake pockets
BED DIMENSIONS
35.25” L x 41.5” W x 11” D
GROUND CLEARANCE
11″
BED CAPACITY
Poly – 9 cu.ft. / Steel – 11 cu.ft. / L-ROSS – 500 lbs. / HD L-ROSS – 600 lbs.
TOWING CAPACITY
1300 lbs.
TOTAL CAPACITY
L-ROSS – 900 lbs. / HD L-ROSS – 1,000 lbs.
WARRANTY
3-year engine / All other 1-year limited
ADDITIONAL FEATURES
3pt lap/shoulder belts for driver and passenger, twin 12V auxiliary outlets for accessories, 12V/18W LED headlights, polyurethane powder paint, 2” front, and rear receiver hitch, poly dump bed standard, weather sealed contoured bench seating, welded steel frame. Complete weather-sealed wiring connections. There is a wide selection of additional accessories and three bed options. Fuel gauge located underside of bed. In-dash, hour/volt meter standard.
VEHICLE PACKAGES
Standard // Powersteering // Sport // Trail // Untamed

Accessories

SHOP ACCESSORIES

What can we make more manageable for you? Accessories are where you make your Landmaster model your own, allowing you to customize your vehicle for the type of work or play you’re doing. We’ve got accessory options for sound, lighting, cargo management, safety, and customization. Making things more straightforward, every Landmaster UTV is built using the same frame design, which means in almost every case, each model universally accepts the accessories. There is no confusing matrix to sort through to ensure you’re buying the right part, and no long holds with customer service to get your question answered. Find the accessory you want, and get to work.

Popular Options

VEHICLE PACKAGES

STANDARD STEERING
POWERSTEERING PACKAGE
TRAIL PACKAGE
Power Steering, Winch, Roof, Split Windshield, HD Bumper, CV Guards, Center Console with Lock, USB Port
CRUISER CLASSIC
Power Steering, Roof, Split Windshield, 25″ Turf/Fusion Tires, Side Mirrors, Rear Mirror, Center Console with Lock, USB Port

SHOCKS

STANDARD SHOCKS
Bed Payload 500lbs
HEAVY DUTY SHOCKS
(+100lbs) Bed Payload 600lbs
KIT, L4 FLIP SEAT SHOCK SET
Only Available With Purchase of Flip Seat

WHEELS / RIMS

8″ FRONT / 10″ BACK STANDARD TRAIL-RIDER WHEEL PACKAGE (PN: 19031)
Trail riding, off-roading, and hill climbing
8″ FRONT / 10″ BACK PREMIUM TRAIL-RIDER WHEEL PACKAGE (PN: 17288)
Black and chrome aluminum rims
8″ FRONT / 10″ BACK STANDARD MAX-TERRAIN HD (PN: 19488)
Ultra-smooth-riding on/off road tires.
8″ FRONT / 10″ PREMIUM MAX TERRAIN WHEEL PACKAGE (PN: 19169)
Ultra-smooth-riding on/off road tires.
25″ CRUISER DOT TIRES IB 12″ FUSION ALLOY WHEELS (PN: 19844)
Gentle on lawns. Smooth on road.
24” TURF & COMMERCIAL TIRES ON 12” STEEL WHEELS (PN: 19793)
25″ GLADIATOR 8 PLY TIRES ON 12″ STEEL WHEELS (PN: CA00057)
8″ front / 10″ back
25″ GLADIATOR 8 PLY TIRES ON 12″ STEEL WHEELS (PN: CA00056)
10″ front / 10″ back

SEAT

STANDARD MARINE GRADE VINYL SEAT
DELUXE UPGRADE SEAT

HOOD COLOR

CAMO HOOD
MIDNIGHT BLUE
GUN METAL GRAY
BLACK HOOD
RED HOOD
BLUE HOOD

BUMPER

STANDARD BUMPER
HEAVY DUTY BUMPER

BED OPTIONS

POLY BED
FLIP SEAT / TAIL GATE
CONVERTIBLE STEEL BED / FLAT BED

ELECTRIC BED OPTIONS

ELECTRIC BED DUMP

LIGHTS & SOUND

FRONT LED LIGHT
STREET LIGHT & HORN PACKAGE
Turn Signals, Horn, Backup Alarm, Tail Lights, Strobe Connect, license plate & bracket
WORK & RIDE LIGHT PACKAGE
Front LED, Dome, & Rear Flood Light
COMMERCIAL SIGNAL PACKAGE
Horn, Strobe, Tail Lights, & Backup Alarm
USB PORT
STROBE
Option for Street Light & Horn Package
2 SPEAKER WET SOUNDS MARINE STEREO SYSTEM
TAIL LIGHT KIT

WINDSHIELDS

POLY CARBONATE SPLIT WINDSHIELD
SINGLE PIECE WINDSHIELD

ROOFS

PLASTIC ROOF

STORAGE & TASK

FRONT RACK
DUAL GUN RACK / TOOL RACK
GRAB HANDLE (SET OF 2)
TOOL CLAMP (SET OF 2)
WINCH – 3,000 LBS. NYLON
CENTER CONSOLE WITH LOCK BOX
STEEL TUNNEL

VEHICLE PROTECTION & ENCLOSURES

FRONT CV GUARD (SET OF 2)
CAB ENCLOSURE

SNOW PLOWS

SNOW PLOW 50″ WINCH POWERED
Requires winch. WINCH NOT INCLUDED.
SNOW PLOW 60″ WINCH POWERED
Requires winch. WINCH NOT INCLUDED.
SNOW PLOW 50″ DUAL ACTUATED
SNOW PLOW 60″ DUAL ACTUATED

MIRRORS & SAFETY

SIDE MIRRORS
REAR MIRROR
2 PASSENGER NET KIT

DECALS

ALL-AMERICAN GRAPHIC
