Description
16GN
Super Duty Single Wheel Tandem Axle Gooseneck
Need more power? The low-profile 16GN Single Wheel Tandem Axle Gooseneck Trailer has you covered. The 16GN is our super-duty, single-wheel gooseneck that delivers a whole lot more cargo capacity, all without the need for dual-wheel axles. For construction, equipment rental companies, and agricultural operations, this heavy-duty, hardworking trailer has all the features you’d expect; from a pierced beam, high tensile steel frame, and dual drop-leg jacks to an integrated toolbox and premium axles. Because for the job that you do from morning until night, you deserve a professional-grade trailer that packs the muscle you need—at a cost that doesn’t blow your budget.
Width:102″
Length:20′, 22′, 25′, 27′, 28′, 30′, 33′, 35′, 36′, 40′
GVWR:17,500 lbs
Cargo Capacity:10,465—12,947 lbs
* Prices and product availability are subject to change without notice. “As Low As” Pricing does not include installation, assembly, shipping, freight or any other dealer fees.
Features
#### 16GN SINGLE WHEEL TANDEM AXLE GOOSENECK TRAILER Need more power? The low-profile 16GN Single Wheel Tandem Axle Gooseneck Trailer has you covered. The 16GN is our super-duty, single-wheel gooseneck that delivers a whole lot more cargo capacity, all without the need for dual-wheel axles. For construction, equipment rental companies, and agricultural operations, this heavy-duty, hardworking trailer has all the features you’d expect; from a pierced beam, high tensile steel frame, and dual drop-leg jacks to an integrated toolbox and premium axles. Because for the job that you do from morning until night, you deserve a professional-grade trailer that packs the muscle you need—at a cost that doesn’t blow your budget. \ #### SPECS Axles 2 – 8,000# Dual Wheel w/ Quick Lubricating Hubs Brakes Forward Self-Adjusting Electric Brakes on Both Axles Suspension Multi-Leaf Slipper Spring w/ Equalizer Coupler 2-5/16″ Ball Adjustable Pipe Safety Chains3/8″ Grade 70 w/ Safety Latch Hook (2 ea) Jack Dual 12,000# Drop Leg Jacks (Bolted on) w/Greasable Handle Frame 12″ I-Beam, 14# (16# I-Beam for 28′ and longer) Cross-Members 3″ Channel Floor Treated Pine or Douglas Fir Ramps 5′ Double Hinged Spring Assist Flip-Over Ramps, (Straight Deck Models do not Include Ramps) Dovetail 5′ Cleated Dovetail (standard on +5 Models) Stake Pockets Stake Pockets Along Both Sides, 24″ O.C. (Quantity Varies by Length) Trailer Plug 7-Way RV Lights Recessed, Grommet-Mounted L.E.D. Lighting Wiring Sealed, Modular Cold-Weather Wiring Harness Tires ST215/75 R-17.5 Load Range H Bolt Pattern 8-Bolt Spare Mount Top of Neck Spare Tire Mount Paint Type Professional Finish w/ Primer Standard Paint Color Black Rubrail 3/8″ Heavy Duty Rub Rail on Both Sides Break-Away Kit Complete Breakaway System w/ Zip(tm) Breakaway Cable and Charger Storage Lockable Toolbox between uprights Cargo Winch Pipe Chain Spools 1-1/4″ Pipe Chain Spools Between Stake Pockets Pockets Steps & Handles (2) Side Bed Steps + Handles
Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
Specifications
Year: |
2024 |
Manufacturer: |
Big Tex Trailers |
Model: |
16GN |
Type: |
Flatbed |
Length: |
20′, 22′, 25′, 27′, 28′, 30′, 33′, 35′, 36′, 40′ |
Width: |
102″ |
Axles: |
2 |
GVWR: |
17500 |
Tongue: |
3″ Channel |
Suspension: |
2 – 8,000# Dual Wheel w/ Quick Lubricating Hubs, Multi-Leaf Slipper Spring w/ Equalizer |
Wheels: |
Black 8 Bolt |
Coupler: |
25/16″ |
Jack: |
Dual 12,000# Drop Leg Jacks (Bolted on) w/Greasable Handle |
Ramp: |
Yes |
Electrical: |
Recessed, Grommet-Mounted L.E.D. Lighting |
Hitch: |
Gooseneck |
Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
Applications
Length: 20′, 22′, 25′, 27′, 28′, 30′, 33′, 35′, 36′, 40′
Width: 102″
