BIG TEX 14ODGN – 8 ft Wide 14000 LB. GVWR Deck Over Gooseneck
The 14OD/14OD-GN Tandem Over The Axle Dump Trailer from Big Tex Trailers is a versatile way to meet your dump trailer needs in a gooseneck configuration. Designed with the user in mind, this unit has a three point rear tailgate in addition to 18โ 10guage fold down sides.
Model(s): 14ODGN-14
Available Sizes: 8 x 14′
Call or Stop by your local Truck’n America today!ย
ย
Features
FEATURES
Lockable Pump & Battery Box Mounted in Front of Bed
J-Hooks for Tie Down
Fully Formed Shroud for Tarp
Self Contained Electric/Hydraulic Scissor Lift
45 Degree Dump Angle
Combo Gate
18โ, 10 Ga. Fold Down Sides
10 Ga. Floor
Stake Pockets (Sides & Front)
EZ Lube Hubs
Dexter Brand Axles
7โ Rear Slide-In Ramps- Standard Equipped
(4) 5/8โ D-Rings Inside Bed
Nev-R-Adjust Electric Brakes
Cambered Axles
Spare Tire Mount
110V Charger
Grommet Mount Sealed Lighting
L.E.D. Lighting Package
Modular Sealed Wiring Harness
Complete Break-A-Way System w/Charger
Radial Tires
Hoist Comparison
Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
Specifications
SPECIFICATIONS
G.V.W.R. 14,000#
G.A.W.R. (Ea. Axle) 7,000#
Coupler 2-5/16โ Adjustable Cast โ OD 2-5/16โ Adjustable Pipe โ OD GN
Jacks OD-12,000# Top Wind Drop Leg OD GN-Dual 12,000# Side Wind Drop Legs
Tongue/Neck 12โ I-Beam
Frame 12โ I-Beam
Crossmembers 4โ I-Beam and 3โ x 3โ Tube
Bed Crossmembers 3โ Channel
Bed Long Sils 5โ Channel
Bed Side Rails 4โ x 3โ Angle
Axles (2) 7,000# EZ Lube w/Elec. Brake
Suspension Multi-Leaf Slipper Spring w/Equalizer
Tire ST235/80 R-16 Load Range E
Wheel 16โ x 6โ; HD White Mod 8 Bolt
Floor 10 Gauge Smooth Steel
Lights LED D.O.T. Stop, Tail, Turn, & Clearance
Elec. Plug 7-Way RV
Finish (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish
Finish Superior Quality Finish is Applied for a Highly Decorative and Protective Finish
Model# Weight Description
14OD 4,550# 96โ x 14โ Over the Axle Bumper Pull Dump
14OD-GN 5,070# 96โ x 14โ Over the Axle Gooseneck Dump
Weights & Capacities
Length Empty Weight Payload Box Capacity
14OD-14โ 4,550# 9,450# 6.2 Cubic Yards
14OD-GN-14โ 5,070# 8,930# 6.2 Cubic Yards
*Weights shown are for base models without options and are estimates only.
