Description
BIG TEX 14GX – 7 ft Wide 14000 LB. GVWR Heavy Duty Gooseneck
The 14GX Tandem Axle Low Profile Extra Wide Dump Trailer from Big Tex Trailers is a great way to gain the features of our popular 14LX in a gooseneck configuration. This unit combines tube frame and structural C channel cross members in addition to the most complete box unit in the industry.
Model(s): 14GX-14, 14GX-16
Available Sizes: 7 x 14′, 7 x 16′
Call or Stop by your local Truck’n America today!ย
Features
FEATURES
Lockable Pump & Battery Box Mounted in Front of Bed
J-Hooks for Tie Down
Fully Formed Shroud for Tarp
Self Contained Electric/Hydraulic Scissor Lift
45 Degree Dump Angle
Combo Gate
24โ, 12 Ga. Sides
10 Ga. Floor
Stake Pockets (Sides)
EZ Lube Hubs
Dexter Brand Axles
110V Charger
(4) 5/8โ D-Rings Inside Bed
Nev-R-Adjust Electric Brakes
Cambered Axles
Spare Tire Mount
Diamond Plate Fenders
Grommet Mount Sealed Lighting
L.E.D. Lighting Package
Protected Wiring
Complete Break-A-Way System w/Charger
Radial Tires
2โ Square Tubing Top Rail
Crank Style Roll Tarp- Standard Equipped
Hoist Comparison
Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
Specifications
SPECIFICATIONS
G.V.W.R. 14,000#
G.A.W.R. (Ea. Axle) 7,000#
Coupler 2-5/16โ Adjustable Pipe
Safety Chains 3/8โ Grd. 70 w/Safety Latch Hook (2 each)
Jacks Dual 12,000# Side Wind Drop Legs
Neck 10โณ I-Beam
Frame 8โ x 3โ Rectangular Tubing
Crossmembers 8โ Channel
Bed Crossmembers 3โ Channel
Bed Long Sils 3โ Channel
Bed Side Rails 6-1/2โ Formed Angle
Fenders Double Square Broke Diamond Plate
Axles (2) 7,000# EZ Lube w/Elec. Brakes
Suspension Multi-Leaf Slipper Spring w/Equalizer
Tire ST235/80 R-16 Load Range E
Wheel 16โณ x 6โณ; HD White Mod 8 Bolt
Floor 10 Gauge Smooth Steel
Lights LED D.O.T. Stop, Tail, Turn, & Clearance
Elec. Plug 7-Way RV
Finish (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish
Finish Superior Quality Finish is Applied for a Highly Decorative and Protective Finish

Model# Weight Description
14GX-14 4,400# 83โ x 14โ Heavy Duty Tandem Axle Gooseneck Dump
14GX-16 4,700# 83โ x 16โ Heavy Duty Tandem Axle Gooseneck Dump
Weights & Capacities
Length Empty Weight Payload Box Capacity
14GX-14โ 4,400# 9,600# 7.2 Cubic Yards
14GX-16 4,700# 9,300# 8.3 Cubic Yards
*Weights shown are for base models without options and are estimates only.
ย Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
Popular Options
POPULAR OPTIONS
Category Description Details
COUPLERS 30,000# Square Adjustable Screw Type Coupler
JACKS Dual 2-Speed Landing Gear
TIRE/WHEEL Spare Tire (ST235/80 R-16 LR-E)
TIRE/WHEEL Tire Upgrade (ST235/85 R-16 LR-G)
TIRE/WHEEL Spare Tire Upgrade (ST235/85 R-16 LR-G)
RAMPS 7โ Slide In Ramps Details
POWER Wireless Remote Details
POWER 5 Watt Solar Charger Details
BODY 24″ Expanded Metal Side Extensions (14′) Details
BODY 24″ Expanded Metal Side Extensions (16′) Details
BODY 3′ Solid Sheet Metal Sides (14′)
BODY 3′ Solid Sheet Metal Sides (16′)
BODY 4′ Solid Sheet Metal Sides (14′)
BODY 4′ Solid Sheet Metal Sides (16′)
BODY Removable Deck on the Neck- Bolt On (8′ W x 6′ L)
