EZ-Dumper – Steel Truck Bed Dump Insert

Call for price

The Original Hydraulic Dump Insert for Trucks (Since 1972) EZ-Dumper® inserts are tough. Our products are designed, engineered and manufactured to deliver dependable performance in tough conditions and extreme environments – the perfect solution for safely & efficiently moving any load from one jobsite to another.Made from steel or stainless steel construction, our inserts are available in standard 8′ size with 2 cubic yard capacity to fit most full-size pickups, and smaller 6′ model with 1.5 cubic yard payload capacity available to fit most short-bed trucks. EZ-Dumper® inserts are designed and manufactured to perform.

Brand: EZ-Dumper

Description

EZ-Dumper® inserts are tough. Our products are designed, engineered and manufactured to deliver dependable performance in tough conditions and extreme environments – the perfect solution for safely & efficiently moving any load from one jobsite to another.

Made from steel or stainless steel construction, our inserts are available in standard 8’ size with 2 cubic yard capacity to fit most full-size pickups, and smaller 6’ model with 1.5 cubic yard payload capacity available to fit most short-bed trucks. EZ-Dumper® inserts are designed and manufactured to perform.

Features

  • The Original Hydraulic Dump Insert for Trucks (Since 1972)
  • 6,000lb Lift Capacity
  • 12 Gauge Steel Floor
  • 14 Gauge Steel Sides
  • Expansion Stake Pockets (outside)
  • Full-length Flat Bar Rub Rails
  • Durable Powder Coat (Black) protects against premature rust and corrosion
  • 2 Cubic Yards of Capacity (8′ Insert, Upgradable to 4 Cubic Yards with Mounted Sideboards and Cab Protector)
  • Convert Your Pickup into a Dump Truck in 2 or 3 Hours without the Overhead Expense
  • Removable, Double-acting Tailgate Lets You Dump, Then Spread What You Dump
  • Full Front-to-Tailgate, Parts and Labor Two Year Warranty
  • Fits Most Full-Size Trucks
  • Short Bed 6′ Truck Insert Also Available (EZ0012TSB)

Specifications

Technical Specs – 8′ Steel Insert
Insert Type EZ0012T 8′ Dump Insert
Bed Length 96″
Unloaded Weight 787 lb
Payload Capacity 6000 lb
Volume Capacity 2 Cubic Yards
Dump Angle 51 Degrees
Frame Construction Structural Steel Angle
Side Steel 14 Gauge
Deck Steel 12 Gauge
Tailgate Double-Acting Removable Spreader
Energy Source Truck Battery
Power Unit Double Acting Monarch Pump
Cylinder(s) Mounted Under Unit
Hydraulics Power Up/Power Down
Remote Control Standard
Tie-down Features Full Length Flat Bar Rub Rails
Expansion Features 8 Stake Pockets (outside)
Lubrication Thread in Grease Fittings on Pivots
Installation Four Bolt-Down Clamps
Standard Color Powder Coat Black
Warranty 2 Years Front to Tailgate
Technical Specs – 6′ Steel Insert
Insert Type EZ0012TSB 6′ Dump Insert
Bed Length 74-1/8″
Unloaded Weight 691 lb
Payload Capacity 6000 lb
Volume Capacity 1.5 Cubic Yards
Dump Angle 51 Degrees
Frame Construction Structural Steel Angle
Side Steel 14 Gauge
Deck Steel 12 Gauge
Tailgate Double-Acting Removable Spreader
Energy Source Truck Battery
Power Unit Double Acting Monarch Pump
Cylinder(s) Mounted Under Unit
Hydraulics Power Up/Power Down
Remote Control Standard
Tie-down Features Full Length Flat Bar Rub Rails
Expansion Features 6 Stake Pockets (outside)
Lubrication Thread in Grease Fittings on Pivots
Installation Four Bolt-Down Clamps
Standard Color Powder Coat Black
Warranty 2 Years Front to Tailgate

Popular Options

Steel Cab Protector

Tarp Kit

20″ High Steel Side and Tailgate Extensions

12″ High Steel Side Extension Bracket Kit (holds 2×12 board)

19″ High Steel Side Extension Bracket Kit (holds 2×12 board)

Coal Chute Spreader Tailgate
