Call for price
Brand: Big Tex Trailers
BIG TEX 10PI – 7 ft Wide – 9990 LB. GVWR Tandem Axle Wood Floor
The 10PI Tandem Axle Pipe Utility Trailer from Big Tex Trailers is perfect for hauling light to medium duty equipment and small tractors. Slide in ramps allow for easy loading and unloading of equipment.
Model(s): 10PI-14, 10PI-16, 10PI-18, 10PI-20
Available Sizes: 7×14′, 7×16′, 7×18′, 7×20′
*** Available in High Mesh Sides ***
Call or Stop by your local Truck’n America today!
FEATURES
(4) Tie Down Pockets on Outside Frame
Forged 2-5/16” Coupler
Fold Back/Wrap Tongue (14’ & Longer)
Set-Back, 7,000# Drop Leg Jack
EZ Lube Hubs
Dexter Brand Axles
Nev-R-Adjust Electric Brakes on All Hubs
Cambered Axles
Tear Drop Style Fenders
2-3/8” Pipe Top Rail
Grommet Mount Sealed Lighting
L.E.D. Lighting Package
Protected Wiring
Spare Tire Mount (Side)
4’ Slide-In Ramps (Channel)
Complete Break-A-Way System w/Charger
Radial Tires NEW!
Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
SPECIFICATIONS
G.V.W.R. 9,990#
G.A.W.R. (Ea. Axle) 5,080#
Coupler Forged 2-5/16”
Safety Chains 1/4” Grd. 70 w/Safety Latch Hook (2 each)
Jack 7,000# Drop Leg (Bolted On)
Tongue 5” Channel Fold Back
Top Rail 2-7/8” Pipe Square Back
Frame 5” x 3” x 1/4” Angle
Crossmembers 3” x 2” x 3/16” Angle
Sides 16” Tall – 3” x 2” x 3/16” Angle
Fenders 9” x 72” Teardrop, Smooth w/Back
Axles (2) 5,200# EZ Lube w/Electric Brakes
Suspension Multi-Leaf Spring w/Equalizer
Tire ST225/75 R-15 Load Range D
Wheel 15″ x 6″; White Spoke 6 Bolt
Floor 2″ Treated Pine or Douglas Fir*
Lights LED D.O.T. Stop, Tail, Turn, & Clearance
Elec. Plug 7-Way RV
Finish (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish
Finish Superior Quality Finish is Applied for a Highly Decorative and Protective Finish
*Douglas Fir Available from Caldwell, ID Facility Only
Model# Weight Description
10PI-14 2,200# 83” x 14’ Pro Series Tandem Axle Pipe Top Utility Trailer
10PI-16 2,260# 83” x 16’ Pro Series Tandem Axle Pipe Top Utility Trailer
10PI-18 2,320# 83” x 18’ Pro Series Tandem Axle Pipe Top Utility Trailer
10PI-20 2,380# 83” x 20’ Pro Series Tandem Axle Pipe Top Utility Trailer
Dimensions
Length A B C
14’ 169-1/2” 103” 66-1/2”
16’ 193-1/2” 115” 78-1/2”
18’ 217-1/2” 127” 90-1/2”
20’ 240” 138” 102”
Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
