BIG TEX 14GP – 7 ft Wide 14000 LB. GVWR Heavy Duty Pipe Top

Call for price

Brand: Big Tex Trailers

Description

BIG TEX 14GP – 7 ft Wide 14000 LB. GVWR Heavy Duty Pipe Top

The 14GP Heavy Duty Pipe Gooseneck Trailer from Big Tex Trailers is our pipe type equipment trailer hauler. This unit combines all of the great features of our Big Tex 14K gooseneck trailers while combining the our pipe rail for added strength and security to strap down any heavy load.

Model(s): 14GP-20, 14GP-24

Available Sizes: 7×20′ 7×24′

Call or Stop by your local Truck’n America today!



Features

FEATURES

Gooseneck with 2-5/16” Adjustable Pipe Coupler

12,000# Drop Leg Jack – Sidwind

(4) Tie Down Pockets on Outside Frame

EZ Lube Hubs

Dexter Brand Axles

Nev-R-Adjust Electric Brakes on All Hubs

Cambered Axles

Heavy Duty 3” Square Tube Top Rail

Double Broke Diamond Plate Fenders

Grommet Mount Sealed Lighting

L.E.D. Lighting Package

Protected Wiring

Spare Tire Mount (Top of Neck)

4’ Slide-In Ramps (Channel)

Complete Break-A-Way System w/Charger

Radial Tires

Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.

Specifications

SPECIFICATIONS

G.V.W.R. 14,000#

G.A.W.R. (Ea. Axle) 7,000#

Coupler 2-5/16” Ball Adjustable Pipe

Safety Chains 3/8” Grd. 70 w/Safety Latch Hook (2 each)

Jack 12,000# Drop Leg Jack- Side Wind

Neck 10” I-Beam

Top Rail 3” Square Tubing

Frame 5” x 3” x 5/16” Angle

Crossmembers 3” Channel on 16” Centers

Uprights 15” Tall, 3” x 2” x 3/16” Angle

Fenders 9” x 72” Double Broke Diamond Plate w/Back

Axles (2) 7,000#, EZ Lube w/Electric Brakes

Suspension Multi-Leaf Slipper Spring w/Equalizer

Tire ST235/80 R-16 Load Range E

Wheel 16″ x 6″; Heavy White Mod 8 Bolt

Floor 2″ Treated Pine or Douglas Fir*

Lights LED D.O.T. Stop, Tail, Turn, & Clearance

Elec. Plug 7-Way RV

Finish (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish

Finish Superior Quality Finish is Applied for a Highly Decorative and Protective Finish

*Douglas Fir Available from Caldwell, ID Facility Only



Model# Weight Description

14GP-20 3,450# 83” x 20’ HD Gooseneck Tandem Axle Pipe Top Lowboy

14GP-24 3,850# 83” x 24’ HD Gooseneck Tandem Axle Pipe Top Lowboy

Dimensions

Length A B C

20’ 240” 160” 80”

24’ 288” 192” 96”

*Weights shown are for base models without options and are estimates only.

 Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.

Popular Options

POPULAR OPTIONS

Category Description

BRAKES Electric Over Hydraulic Brakes (Drum)

JACKS Dual 12,000# Drop Leg Jacks

TIRE/WHEEL Spare Tire (ST235/80 R-16 LR-E)

TIRE/WHEEL Tire Upgrade (ST235/85 R-16 LR-G)

TIRE/WHEEL Spare Tire Upgrade (ST235/85 R-16 LR-G)

RAMPS 5’ Stand up Ramps in Lieu of Slide In

RAMPS 4’ Heavy Duty Integrated Ramp Gate w/Gas Shock Assist in Lieu of Ramps

RAMPS 5’ Heavy Duty Integrated Ramp Gate w/Gas Shock Assist in Lieu of Ramps (Split Gate)

BODY Enclose Sides w/ Expanded Metal (Per Square Foot)

BODY Enclose Sides w/ Sheet Metal (Per Square Foot)

BODY 2′ High Sides (Open)

BODY 3′ High Sides (Open)

BODY 4′ High Sides (Open)

BODY 1/8” Diamond Plate Steel Floor (Per Square Foot)

CARGO CONTROL Lockable Tool Box Between Gooseneck Risers (Dual Jacks Required)

CARGO CONTROL Additional Tie Down Pockets (Each)

CARGO CONTROL B40 5/8″ D-Ring (Each)
