BIG TEX 20PH – 8.5 ft Wide 20000 LB. GVWR Economy Dual Wheel Pintle Deck Over

Call for price

Brand: Big Tex Trailers

Description

BIG TEX 20PH – 8.5 ft Wide 20000 LB. GVWR Economy Dual Wheel Pintle Deck Over

The 20PH from Big Tex Trailers is an economy tandem dual wheel pintle hauler. Standard features include two 10K axles, a spare tire and wheel, and L.E.D. lighting package.

Model(s):ย 20PH-20+5

Available Sizes: 8.5×20’+5′

Call or Stop by your local Truck’n America today!ย

ย

Features

FEATURES

3โ€ ID Pintle Ring

12,000# Drop Leg Jack- Top Wind (Bolted On)

102โ€ Overall Width

Low Profile Bed, Pierced- Beam Frame

(2) Side Bed Steps

3/8โ€ Heavy Duty Rub Rail

Tie Down Pockets Along Sides, 24โ€ On Center

1-1/4โ€ Pipe Chain Spools Between Tie Down Pockets

Oil Bath Hubs

Dexter Brand Axles

Cambered Axles

Forward Self Adjusting Brakes

Grommet Mount Sealed Lighting

L.E.D. Lighting Package

Modular Sealed Wiring Harness

Spare Tire Mount (Inside Tongue)

5โ€™ Dovetail w/5โ€™ Double Hinged Flip-Over Ramps

Complete Break-A-Way System w/Charger

Radial Tires

Mudflaps

Spare Tire & Wheel- Standard Equipped NEW!

Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.

Specifications

SPECIFICATIONS

G.V.W.R. 20,000#

G.A.W.R. (Ea. Axle) 10,000#

Coupler 3โ€ณ ID Pintle Ring

Safety Chains 3/8โ€ Grd. 70 w/Safety Latch Hook (2 each)

Jack Single 12,000# Drop Leg Jack (Bolted On)

Tongue 12โ€ I-Beam; Integral with Frame

Top Rail None

Frame 12โ€ I-Beam

Crossmembers 3โ€ Channel

Side Rails 5โ€ Channel w/Rub Rail, Stake Pockets on 24โ€ Centers, and Chain Spools

Axle (2) 10,000# Dual Wheel Electric Brakes

Suspension Multi-Leaf Slipper Spring w/Equalizer

Tire ST235/80 R-16 Load Range E Dual

Wheel 16โ€ณ x 6โ€ณ; Dual Wheel 8 Bolt

Floor 2โ€ณ Treated Pine or Douglas Fir*

Lights L.E.D D.O.T. Stop, Tail, Turn, & Clearance

Elec. Plug 7-Way RV

Finish (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish

Finish Superior Quality Finish is Applied for a Highly Decorative and Protective Finish

*Douglas Fir Available from Caldwell, ID Facility Only

20PH line drawing

Model# Weight Description

20PH-20+5 5,100# 102โ€ x 20โ€™ + 5โ€™ Economy Tandem Dual Wheel Pintle

Dimensions

Length A B C

20 + 5 240 180โ€ 60โ€

*Weights shown are for base models without options and are estimates only.

ย Truck’n America strives to ensure the accuracy of information presented on this site. However there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.

Popular Options

POPULAR OPTIONS

No Additional Options Available
